TD-24/1250-20型
The product adopts a single-step sealing and evacuation process and a ceramic casing, utilizing a longitudinal magnetic field contact structure. It features high breaking capacity, excellent insulation performance, strong arc-extinguishing capability, long service life, and compact size. Additionally, it offers the advantages of simple maintenance,
-
Energy conservation
-
Material saving
-
Fireproof
-
Explosion-proof
-
Small size
-
Long lifespan
-
Low maintenance costs
-
Reliable operation
-
Pollution-free
Product Parameter
-
GLVAC modelTD-24/1250-20型
-
Rated Current （A）1250
-
Rated Voltage (kV)24
-
Rated Breaking Current(kA)20
-
Rated Breaking Current Times30
-
Rated Short-time(1min) Power-Frequency Withshand Voltage(kV)65*
-
Rated Lightning Impulse Withstand Voltage(kV)125*
