TJ-1.14/160B
-
Power system
-
Metallurgy
-
Coal mining
-
Petroleum
-
Chemical
-
Electric railway
TJ-1.14/160B
The product adopts a single-step sealing and evacuation process and a ceramic casing, utilizing a longitudinal magnetic field contact structure. It features high breaking capacity, excellent insulation performance, strong arc-extinguishing capability, long service life, and compact size. Additionally, it offers the advantages of simple maintenance,
-
Energy conservation
-
Material saving
-
Fireproof
-
Explosion-proof
-
Small size
-
Long lifespan
-
Low maintenance costs
-
Reliable operation
-
Pollution-free
Product Parameter
-
GLVAC modelTJ-1.14/160B
-
Rated Current (A)160
-
Rated Voltage (kV)1.14
-
Rated Short-Current(kA/Times)1.6/100
-
Rated Breaking Capacity(kA/Times)1.28/25
-
Limited Breaking Capacity(kA/Times)2/3
-
Rated Short-time(1min) Power-Frequency Withshand Voltage(kV)10
Get Professional Solutions
We are looking forward to engaging with you to explore more solutions for electric vacuum devices.
