GL22

  • Short wave communication

  • Communication satellites

  • Radar

  • Submarine cable

  • RF applications

  • High voltage testing instruments

  • Semiconductor equipments


GL22

Tungsten contact for power switching. Vacuum as dielectric, low contact resistance.

  • Handling high power

  • Working under harsh conditions such as high voltage and high current

  • High reliability

  • Long lifespan

Product Parameter

  • GLVAC model
    GL22
  • Rated Working Voltage(kV)
    26
  • Load Switch
    Yes
  • Rated Open Voltage(kV Peak) DC or 60Hz
    25
  • Max CONT. Current(A)
    65
  • Contact Form
    SPST-NO
  • Contact Capacitance(pF)
    2.5/2.5
  • Max Contact Resist(0hms)
    0.01
  • Max Open Time(ms)
    18
  • Max Rel. Time(ms)
    10
  • Shock 11ms 1/2 Sine(gpeak)
    30
  • Weight Nom(g)
    342
