G2L

  • Short wave communication

  • Communication satellites

  • Radar

  • Submarine cable

  • RF applications

  • High voltage testing instruments

  • Semiconductor equipments


G2L

Latching coils for low power consumption and to ensure relay will remain in last position, even when no voltage is applied to the coil. Sealed 70kV isolation in about 6.3 cubic inch(100 cubic cm) package-your will be system the smallest in the industry.

  • Handling high power

  • Working under harsh conditions such as high voltage and high current

  • High reliability

  • Long lifespan

Product Parameter

  • GLVAC model
    G2L
  • Rated Working Voltage(kV)
    15
  • Load Switch
    No
  • Rated Open Voltage(kV Peak) DC or 60Hz
    15
  • Max CONT. Current(A)
    50
  • Contact Form
    SPDT-Latching
  • Contact Capacitance(pF)
    0.5/1
  • Max Contact Resist(0hms)
    0.012
  • Max Open Time(ms)
    15
  • Max Rel. Time(ms)
    9
  • Shock 11ms 1/2 Sine(gpeak)
    50
  • Weight Nom(g)
    85
