GR5LTA

  • Short wave communication

  • Communication satellites

  • Radar

  • Submarine cable

  • RF applications

  • High voltage testing instruments

  • Semiconductor equipments


GR5LTA

Vacuum dielectric offers low stable contact resistance. All PC pin or PC pin & flying lead connections provide mounting and connection versatility.

  • Handling high power

  • Working under harsh conditions such as high voltage and high current

  • High reliability

  • Long lifespan

Product Parameter

  • GLVAC model
    GR5LTA
  • Rated Working Voltage(kV)
    10KV
  • Load Switch
    No
  • Rated Open Voltage(kV Peak) DC or 60Hz
    10
  • Max CONT. Current(A)
    5
  • Contact Form
    SPST-NO
  • Contact Capacitance(pF)
    1/8
  • Max Contact Resist(0hms)
    0.25
  • Max Contact Resist(0hms)
    2
  • Max Open Time(ms)
    2
  • Max Rel. Time(ms)
    100
  • Weight Nom(g)
    28
