GL12SP

  • Short wave communication

  • Communication satellites

  • Radar

  • Submarine cable

  • RF applications

  • High voltage testing instruments

  • Semiconductor equipments


GL12SP

Smallest high voltage relay with double pole double throw. Durable tungsten contacts for hot load switching.

  • Handling high power

  • Working under harsh conditions such as high voltage and high current

  • High reliability

  • Long lifespan

Product Parameter

  • GLVAC model
    GL12SP
  • Rated Working Voltage(kV)
    8
  • Load Switch
    Yes
  • Rated Open Voltage(kV Peak) DC or 60Hz
    8
  • Max CONT. Current(A)
    10
  • Contact Form
    DPDT
  • Contact Capacitance(pF)
    0.8/1.5
  • Max Contact Resist(0hms)
    0.02
  • Max Open Time(ms)
    15
  • Max Rel. Time(ms)
    9
  • Shock 11ms 1/2 Sine(gpeak)
    30
  • Weight Nom(g)
    71
