CKTBT300/15/168
Trimming vacuum capacitors integrate the stability of fixed capacitors with the flexibility of variable capacitors, and are used to compensate for subtle yet critical impedance differences that arise during the matching process.
-
Long life
-
Reliable quality
-
High rated withstand voltage
-
High rated current
-
Fast tuning speed
-
Wide tuning range
Product Parameter
-
GLVAC modelCKTBT300/15/168
-
Capacitance(pF)300
-
Cmin(pF)290
-
Cmax(pF)310
-
Voltage(Peak test)(kV)25
-
Voltage(RF working)(kV)15
-
Current(A)168
-
Diameter(mm)64
-
Length(mm)95
