GDCWM-75LJ
The GDCWM-75LJ magnetron is a high-power microwave source (continuous wave high-power magnetron) specifically designed and manufactured for 75kW industrial heating equipment, operating at fixed frequencies of 915MHz, 896MHz, 922MHz, and 929MHz. The anode employs water cooling, and the magnetic field is structured with an electromagnet.
-
High efficiency
-
Long lifespan
-
Fast tuning speed
Product Parameter
-
GLVAC modelGDCWM-75LJ
-
Frequency(MHz)896、915、922、929
-
Power output(kW)75
-
Anode voltage(kV)19
-
Anode current(A)6
-
Weight(kg)7
