GD1549

  • Laser

  • Radar

  • Pulse modulator

  • Medical linear accelerator

  • Crowbar protection

  • Research electronic instruments and equipment


GD1549

Hydrogen thyratrons use hydrogen or deuterium as arc discharge dielectric,which have the advantages of high working voltage,high pulse current,quick and steady fire lighting,low trigger voltage,high efficiency,long life,light weigh,small size,easy for use,etc.

  • Main features

  • High power

  • High pulse current

  • Rapid and stable ignition

  • Low trigger voltage

  • High repetition frequency

  • Reliability

  • High efficiency

  • Light weight

  • Small size

  • Easy to use

Product Parameter

  • GLVAC model
    GD1549
  • Peak Anode Voltage(kV)
    35
  • Peak Anode Current(A)
    10000
  • Average Anode Current(A)
    15
  • Unloaded drive pulse voltage(V)
    1000-2000
  • Minimum heater time(min)
    10
