YL75-9-1500M
-
Semiconductor matching system
-
Photovoltaic heterojunction
-
Induction heating
-
Medium heating
-
Communication broadcasting
YL75-9-1500M
The main features of motorized vacuum capacitors include: easy setup, high precision, integration-friendly design, efficient control, and wide applicability. They have become an ideal choice for high-frequency plasma technology and RF power impedance matching.
-
Long life
-
Reliable quality
-
High rated withstand voltage
-
High rated current
-
Fast tuning speed
-
Wide tuning range
Product Parameter
-
GLVAC modelYL75-9-1500M
-
Capacitance(pF)1500
-
Cmin(pF)150
-
Voltage(Peak test)(kV)9
-
Voltage(RF working)(kV)5.4
-
Current(A)95
-
Diameter(mm)75
-
Length(mm)209.1
