CKTBM500/12/94N1(I)
The main features of motorized vacuum capacitors include: easy setup, high precision, integration-friendly design, efficient control, and wide applicability. They have become an ideal choice for high-frequency plasma technology and RF power impedance matching.
-
Long life
-
Reliable quality
-
High rated withstand voltage
-
High rated current
-
Fast tuning speed
-
Wide tuning range
Product Parameter
-
GLVAC modelCKTBM500/12/94N1(I)
-
Capacitance(pF)500
-
Cmin(pF)50
-
Voltage(Peak test)(kV)12
-
Voltage(RF working)(kV)7.2
-
Current(A)94
-
Diameter(mm)64
-
Length(mm)210.4
